Hedge Clipper

OperatOr's Manual

aIr fIlter

Level 1.

Parts required: REPOWER

AIR & FUEL FILTER KIT.

1. Close choke (Cold Start Position [ ]). This prevents dirt from

entering the carburetor throat when the air lter is removed. Brush

accumulated dirt from air cleaner area.

2. Remove air lter cover. Brush dirt from inside cover.

3. Remove air lter and lightly brush debris from lter. Replace lter

if it is damaged, fuel soaked, very dirty, or the rubber sealing edges

are deformed.

4. If lter can be reused, be certain it:

• Fits tightly in the air lter cavity.

• Is installed with the original side out.

5. Install air lter cover.

fuel fIlter

Level 1.

Parts required: REPOWER

AIR & FUEL FILTER KIT

DANGER

Fuel is VERY ammable. Use extreme care when mixing, storing

or handling.

1. Use a clean rag to remove loose dirt from around fuel cap and

empty fuel tank.

2. Use the “fuel line hook” to pull the fuel line and lter from the tank.

3. Remove the lter from the line and install the new lter.

NOTE

Federal EPA regulations require all model year 2012 and later gasoline powered engines produced for sale in the

United States to be equipped with a special low permeation fuel supply hose between the carburetor and fuel tank.

When servicing model year 2012 and later equipment, only fuel supply hoses certied by EPA can be used to replace

the original equipment supply hose. Fines up to $37,500 may be enforced for using an un-certied replacement part.
